WHEEL DIAMETER

Tire Size	Stock Number	Tread Depth(1/32 in)	Overall Dia (in)Inflated Dimensions	Overall Width (in)Inflated Dimensions	Approved Rim Width RangeMin-(Measuring)-Max (in)	Maximum Load (lbs.) @ Press. (PSI)	Weight (lbs)
265/70R16 116T XL††	216650	13.1	30.63	10.71	7.0-(8.0)-9.0	2756 @ 50	39.20
LT265/75R16 E 123/120Q††	216660	16.8	31.65	10.51	7.0-(7.5)-9.0	3415 @ 80	49.25
LT285/75R16 E 126/123Q††	216670	17.0	32.83	11.26	7.5-(8.0)-9.5	3750 @ 80	55.87

Tire Size	Stock Number	Tread Depth(1/32 in)	Overall Dia (in)Inflated Dimensions	Overall Width (in)Inflated Dimensions	Approved Rim Width RangeMin-(Measuring)-Max (in)	Maximum Load (lbs.) @ Press. (PSI)	Weight (lbs)
235/75R17 113S XL††	216680	12.6	30.87	9.25	6.0-(6.5)-8.0	2535 @ 50	34.17
LT235/80R17 E 120/117R††	216400	16.5	31.81	9.25	6.0-(6.5)-8.0	3085 @ 80	42.62
LT245/70R17 E 119/116R††	216620	17.0	30.55	9.76	6.5-(7.0)-8.0	3000 @ 80	46.25
LT245/75R17 E 121/118R††	216180	17.0	31.50	9.76	6.5-(7.0)-8.0	3195 @ 80	46.30
255/70R17 116S XL††	216690	13.0	31.10	10.24	6.5-(7.5)-8.5	2756 @ 50	38.18
265/65R17 116T XL††	216580	12.9	30.55	10.71	7.5-(8.0)-9.5	2756 @ 50	37.81
265/70R17 115T††	216260	13.1	31.65	10.71	7.0-(8.0)-9.0	2679 @ 44	40.85

Tire Size	Stock Number	Tread Depth(1/32 in)	Overall Dia (in)Inflated Dimensions	Overall Width (in)Inflated Dimensions	Approved Rim Width RangeMin-(Measuring)-Max (in)	Maximum Load (lbs.) @ Press. (PSI)	Weight (lbs)
P255/70R18 112T††	216640	13.0	32.09	10.24	6.5-(7.5)-8.5	2469 @ 44	41.96
265/60R18 114T XL††	216440	12.9	30.51	10.71	7.5-(8.0)-9.5	2601 @ 50	40.26
265/65R18 116T††	216240	12.9	31.54	10.71	7.5-(8.0)-9.5	2756 @ 50	43.19
LT265/65R18 E 122/119R††	216520	16.0	31.54	10.71	8.0-(8.0)-9.5	3305 @ 80	49.03
265/70R18 116T††	216500	13.1	32.64	10.71	7.0-(8.0)-9.0	2756 @ 44	42.42
LT265/70R18 E 124/121R††	216140	16.0	32.64	10.71	7.0-(8.0)-9.0	3525 @ 80	49.86
275/65R18 116T XL††	216250	13.0	32.09	10.98	7.5-(8.0)-9.5	2756 @ 50	46.69
LT275/65R18 E 123/120S††	216110	16.0	32.09	10.98	8.0-(8.0)-9.5	3415 @ 80	52.47
285/60R18 120S XL††	216450	13.6	31.46	11.50	8.0-(8.5)-10.0	3086 @ 50	49.07
LT285/60R18 E 122/119S††	216630	15.6	31.46	11.50	8.5-(8.5)-10.0	3305 @ 80	53.34

Terra Grappler G2

Name: Terra Grappler G2 All Terrain Light Truck Tire
Brand: Nitto
Rating: 3.96 (311 reviews)

All-Terrain Tire

The Terra Grappler^® G2 is specifically designed to meet your everyday on and off-road adventures.

UTQG TREADWEAR
P-Metric and Metric Sizes Only: 600

TRACTION: A

TEMPERATURE: B

Find a Store

For every adventure

Whether you’re commuting to work, towing a trailer, or headed up to your favorite mountain trail, the balanced off-road and on-road performance of the Terra Grappler^® G2 will get you to your destination with confidence. *Select Terra Grappler G2 sizes are 3Peak rated for additional all-weather capability.

FEATURES & Benefits

TREADWEAR WARRANTY

Terra Grappler^® G2 features a brand new compound new to Nitto’s Grappler line of products. Through the introduction of new materials, Nitto was able to maintain the versatile all-terrain compound while increasing the longevity of the treadwear. For the first time Nitto is backing an all-terrain product with a limited treadwear warranty which covers 50,000 miles for LT-metric and flotation sizes, and 65,000 miles for hard metric sizes. See warranty for complete details.

FEATURES & Benefits

Tough enough

COUPLING JOINTS

Nitto decided to reinforce the coupling joints in the Terra Grappler^® G2, which connects the outer most tread blocks to the center blocks, to increase the block edge rigidity.

FEATURES & Benefits

Always looking good

FULL DEPTH SIPES

Terra Grappler^® G2 is equipped with full depth siping. Not only do the full depth sipes offer a functional benefit, it helps maintain the appearance of the tread design as the tire wears.

FEATURES & Benefits

Choose any line

SHOULDER LUGS

The staggered shoulder lugs on the Terra Grappler^® G2 provides additional biting edges in off-road conditions. Furthermore, the new sidewall designs connect the sidewall lugs starting from the shoulder block down to the middle of the sidewall surface.

FEATURES & Benefits

Tread quietly

VARIABLE PITCH TREAD BLOCKS

Computer analyzed tread block arrangement reduces tire noise normally heard at highway driving speeds.

FEATURES & Benefits

Show your personality

DUAL SIDEWALL DESIGNS

Like all Grapplers, the Terra Grappler^® G2 features two bold sidewall designs. One side features a raised thunderbolt pattern like the original Terra Grappler^®. The other side features a new aggressive “blade” design which extends from the shoulder tread block down to the sidewall.
